DIN-RAIL BOX PC
DIN-rail BOX PCs are the ideal solution for integrating computing power directly inside electrical cabinets and industrial automation control panels. Their clip-on design allows them to be mounted onto standard DIN rails (EN 50022), enabling fast and organized installation without the need for additional panel drilling while complying with industrial electrical wiring standards.
Filtra per
-
- Select a value
-
- Select a value
-
Results
Sort by
Elements per page
No exact match, try with fewer filters or a more generic term
Compact Design and Simplified Installation
The DIN-rail form factor optimizes space utilization inside electrical cabinets. These industrial computers occupy a footprint comparable to a standard circuit breaker or relay while integrating modern processors, RAM, storage, and multiple communication interfaces. Their fanless design eliminates the primary source of mechanical failure, significantly reducing maintenance costs and ensuring silent operation.
Performance and Technical Features
Industrial DIN-rail BOX PCs are available with processors ranging from Intel® N-series, Atom®, Celeron®, and Pentium® CPUs up to the latest Intel® Core™ Ultra 7 platforms, featuring optimized TDPs for passive cooling. Their connectivity options are specifically designed for automation applications and include RS-232/485 serial ports for communication with PLCs and legacy devices, Gigabit Ethernet ports for networking, USB ports for peripherals and configuration, and, in some models, expansion slots for additional I/O cards. Support for Windows 10/11 IoT Enterprise, Windows 11 Professional, Linux, and real-time operating systems such as VxWorks and QNX makes them suitable for virtually any supervision and control software environment.
Built for Harsh Industrial Environments
Designed for demanding industrial conditions, DIN-rail BOX PCs feature extended operating temperature ranges from -40°C to +70°C, wide-range DC power inputs (9–36V DC) with reverse polarity and surge protection, vibration and shock resistance certifications (MIL-STD-810G), and resistance to dust and humidity. These characteristics ensure reliable operation in critical environments, from foundries and cold-storage facilities to industrial vehicles and outdoor infrastructure installations.
Typical Applications
DIN-rail BOX PCs are commonly used as industrial protocol gateways (converting RS-485 or CAN networks to Ethernet), data concentrators for sensor networks, controllers for small-to-medium SCADA systems, edge computing platforms for processing IoT data before cloud transmission, and onboard computers for industrial machinery where installation space is limited.
Why Choose Digimax
Digimax offers DIN-rail BOX PCs from leading manufacturers including Advantech, AAEON, and IEI Technology, with hardware configurations tailored to different budgets and application requirements. Our technical team can recommend the most suitable platform based on the software to be deployed, installation conditions, and connectivity requirements, ensuring the optimal solution for your industrial automation project.
FAQ - Frequently Asked Questions
What makes a DIN-rail BOX PC different from a standard industrial PC?
A DIN-rail BOX PC is specifically designed for mounting on standard DIN rails inside electrical control cabinets. It is characterized by its compact clip-on form factor, passive cooling design (fanless operation), wide-range DC power input, certified resistance to vibration and shock, and extended operating temperature range. Rather than being simply a miniaturized computer, it is engineered from the ground up for demanding industrial electrical environments.
Which operating systems are supported by industrial DIN-rail BOX PCs?
DIN-rail BOX PCs support a wide range of operating systems, including Windows 10/11 IoT Enterprise for maximum software compatibility, Windows 11 Professional, Linux distributions such as Ubuntu, Debian, and Yocto, as well as real-time operating systems like VxWorks and QNX for deterministic control applications. The most suitable choice depends on the application software and real-time requirements.
Are DIN-rail BOX PCs suitable for Industrial IoT edge computing applications?
Absolutely. The computing performance of modern DIN-rail BOX PCs, combined with integrated industrial communication interfaces such as RS-485, CAN, and Gigabit Ethernet, and support for IoT frameworks including Node-RED, MQTT, and Docker, makes them ideal platforms for industrial edge computing. They can collect and preprocess sensor data, execute local AI and machine learning algorithms, and transmit only relevant information to cloud platforms.
How is a DIN-rail BOX PC powered inside an electrical cabinet?
Industrial DIN-rail BOX PCs typically operate on DC power in the 9–36V range, making them fully compatible with common 12V and 24V industrial power supplies used in electrical cabinets. They generally include protection against reverse polarity, overvoltage, and overcurrent conditions. Some models also support redundant power inputs for high-availability applications.
What is the difference between a DIN-rail BOX PC and an Expansion BOX PC?
A DIN-rail BOX PC features a fixed form factor optimized for DIN-rail installation, with integrated I/O interfaces but limited hardware expandability. An Expansion BOX PC, on the other hand, includes expansion slots such as PCIe or PCI, allowing the addition of I/O cards, data acquisition boards, specialized communication interfaces, or GPUs for machine vision applications. DIN-rail BOX PCs are typically chosen for compactness and ease of installation, while Expansion BOX PCs are preferred when greater flexibility and hardware customization are required.
